Liquid Leak Detector Fisher Labs XLT17 w/Big Foot Microphone

Description :

Fisher’s XLT-17 is a liquid leak detector that finds leaks in four easy steps: by electronically amplifying leak sounds, selectively filtering out noise, isolating the leak sound, and leading the operator to the source of the leak. The XLT-17 leak detector is built to perform and priced to compete. The XLT-17 comes standard with Fisher’s Multi-Sensor which has superior leak detection capabilities. The Multi-Sensor is in an extremely compact design with improved sensor electronics and better sensitivity to leaks.

2 Year Warranty: Fisher warrants the XLT-17 to be free of defects in materials and workmanship when it is shipped from the factory. The terms of this warranty are fully explained in a warranty registration card that accompanies the instrument. Complete factory and field service facilities support the warranty.

Features:

• Detects and pinpoints liquid leaks in pipes
• 4 Frequency Filters: Low Pass, High Pass, Band Pass and All Pass
• Last setting memory feature
• Touch-control keypad
• Shielded sensor for reduced response to outside noise
• Improved headset for clearer sound response
• Automatic battery test – real time voltage level
• Operates on two 9 volt batteries
• Compact control box that can be worn around the neck or over the shoulder with an attachable strap
• Heavy duty carrying case

Specifications:

• Operating Frequency:  60 Hz – 6 kHz, Gain = 60 db; 20 Hz – 60 Hz, Gain > 55 dB
• Filter Types and Frequency Ranges:   All Pass: 60 Hz to 6 kHz; Low Pass: Adjustable cut-off frequency from 150 Hz to 2.4 kHz; High Pass: Adjustable pass band frequency from 150 Hz to 2.4 kHz; Band Pass: Adjustable center frequency from 150 Hz to 2.4 kHz
• Output Indications:  Audio: High performance headphones (64 ohms)
• Visual: LCD bargraph and 2-digit numeric display
• Grade of Protection: Splash Proof
• Battery Test:  Automatic, real time battery level indicator
• Battery Quantity/Type:  Two, 9 Volt alkaline
• Battery Life:  50 Hours (approximate)
• Carrying Case Dimensions:  21”x 6”x 14”
• Weight:  10 lbs

What’s in the Box:

• (1) Control Box
• (1) Multi-Sensor
• (1) Set Sound Rods
• (1) Multi-Sensor Handle
• (1) Sensor Cable
• (1) Headphones
• (1) Carrying Strap/Housing Mounting Bracket
• (1) Heavy duty carrying case
• (1) Manual
